Plastic Rollers

480 Plastic Roller

Tube Diameter - 48.3 x 2.8mm Dynopipe
Bearing - Bushed Bearing (480)
Shaft Size - 6mm, 8mm, 9.5mm, 10mm or 12mm
Shaft Materials - Mild or Stainless Steel

• Rated speed 20m/min (speed can be increased with decreased load).
• Max. static load 30kg.
• For central point load, reduce load rating by 1/3.

Common uses;
- General purpose gravity rollers.
- Belt supports.
- Food factories.
- Fruit handling elevators

Configure your roller

Features, Benefits & Uses

Specifications

• Load Rating kg (Minimum applies).

Dyno Conveyors 480 Plastic PVC Roller 48mm Diameter Roller Load Rating

* Shaded sizes not recommended

Downloads

480 Roller Technical Information
